DT-9887

The DT-9987 is a high-performance True RMS Industrial Digital Multimeter designed for professionals who require fast, accurate, and reliable measurements. Featuring a large 50,000 counts 320 x 240 TFT color LCD display, this multimeter offers advanced functionalities such as data logging, trend capture, and Bluetooth connectivity. It is ideal for troubleshooting and monitoring equipment in industrial environments, ensuring safety and efficiency.

Key Features

• Large TFT Color LCD Display: 50,000 counts, 320 x 240 resolution for clear and detailed readings.

• Data Logging and Trend Capture: Records events and trends for easy review and analysis.

• Bluetooth Interface: Facilitates easy data transfer and accuracy calibration.

• True RMS Measurements: Accurate AC, AC+DC True-RMS measurements.

• Peak Capture: Records transients as fast as 250µs.

• Min/Max/Average with Time Stamp: Tracks signal fluctuations over time.

• Moto Winding and Low Ohm Measurement: 50Ω measurement range for precise low resistance readings.

• 4-20mA Process Loop Measurements: Provides % reading for process control applications.

• Low Pass Filter: Ensures accurate measurements in noisy environments.

• IP67 Rating: Waterproof and dustproof design for rugged use.

• Meterbox Pro & Cloud Service: Advanced data management and analysis.

Specifications

• Voltage DC:

  • Maximum: 1000V

  • Resolution: 1µV

  • Accuracy: ±(0.025% + 5)

• Voltage AC:

  • Maximum: 1000V

  • Resolution: 1µV

  • Accuracy: ±(0.4% + 40)

• Current DC:

  • Maximum: 10A

  • Resolution: 0.01µA

  • Accuracy: ±(0.15% + 2)

• Current AC:

  • Maximum: 10A

  • Resolution: 0.01µA

  • Accuracy: ±(0.6% + 5)

• Temperature:

  • Range: -50°C to 1000°C

  • Resolution: 0.1°C

  • Accuracy: ±(1.0% + 2.5°C)

• Resistance:

  • Maximum: 50MΩ

  • Resolution: 0.01Ω

  • Accuracy: ±(0.05% + 2)

• Capacitance:

  • Maximum: 10mF

  • Resolution: 0.001nF

  • Accuracy: ±(1.0% + 5)

• Frequency:

  • Maximum: 10MHz

  • Resolution: 0.01Hz

  • Accuracy: ±(0.005% + 1)

• Diode and Continuity: Yes

• PC Interface: Bluetooth

• Power Supply: 18 hours Li-ion rechargeable battery; AC adaptor/charger

Safety Conformance

• EN61010-1: CAT IV 600V, CAT III 1000V

• Input Protection: 1000V on all ranges

• Fuse Protection: 10A/1000V & 0.8A/1000V fuses on current ranges

Product Dimensions and Weight

• Size (HxWxD): 220mm x 96mm x 60mm

• Weight: 631g

Accessories

• Included Accessories: Test leads, Li-ion batteries, Type K temperature probe, AC adaptor, software, gift box with carrying case.

Why Choose DT-9987?

• High Accuracy and Reliability: Ensures precise and dependable measurements across various parameters.

• Advanced Features: Data logging, trend capture, and Bluetooth connectivity enhance usability and data management.

• User-Friendly: Large TFT color LCD display and intuitive interface make it easy to use.

• Durable and Safe: Double molded plastic housing and IP67 rating ensure rugged and safe operation.

• Versatile Applications: Suitable for a wide range of industrial and professional applications.
