DT-9382 & DT-9382B Professional AC/DC Clamp Meters with Color Display & Bluetooth

The DT-9382 and DT-9382B represent the premium tier of clamp meters, combining top-tier measurement capabilities with advanced visualization and connectivity features. Both models feature a vibrant 1.8" TFT color LCD display, True RMS measurement, and support for an optional flexible 3000A current clamp. The key distinction is the Bluetooth data connectivity present in the DT-9382, which is absent in the DT-9382B.

Key Features Common to Both Models (DT-9382 & DT-9382B):

Premium Color Display: Large 1.8-inch TFT color LCD with 6000-count resolution provides exceptional clarity for numeric readings, trend graphs, and menu navigation.
AC/DC Clamp & True RMS: Measures both AC and DC current up to 1000A via the rigid jaw, with True RMS accuracy for correct readings on distorted waveforms.
Extended Current Range (Optional): Supports an optional flexible current probe (AC only) that extends the measurement range up to 3000A, ideal for large conductors and busbars.
Advanced Data Visualization & Logging:
- Trend Capture Function: Graphically plots measurements (e.g., current, voltage) over time directly on the color screen to identify fluctuations and patterns.
- Data Review: Stores and allows review of the last 100 graph screenshots for post-analysis.
Full-Featured Multimeter: Measures AC/DC Voltage (1000V), Resistance (60MΩ), Capacitance (100mF), Frequency (10kHz), and Temperature.
Comprehensive Diagnostic Suite: Includes Inrush Current, Low Impedance (LoZ) Mode, Low Pass Filter (LPF), Non-Contact Voltage (NCV), flashlight, data hold, and relative function.
Rugged Design: Double-molded housing with a standard 35mm jaw.

DT-9382 vs. DT-9382B Detailed Comparison Table

Feature & Specification	DT-9382	DT-9382B	Impact & Advantage
Display & Interface
Display Type & Counts	1.8" TFT Color LCD, 6000 counts	1.8" TFT Color LCD, 6000 counts	Identical premium color display for excellent readability and graphical data presentation.
Connectivity
Bluetooth Interface	Yes (Bluetooth 4.0)	No	The DT-9382's key differentiator. Enables wireless data transfer to a smartphone/tablet app ("Meterbox Pro" or similar) for remote monitoring, data logging, report generation, and cloud storage.
PC Software & USB Cable	Included	Not Included (Typically)	DT-9382 includes software for data management via a (likely optional) USB connection. DT-9382B relies on the meter's screen for data review.
Core Electrical Measurements
AC Current (ACA) - Rigid Jaw	0.1A ~ 1000A	0.1A ~ 1000A	Identical high-capacity AC current measurement with True RMS accuracy.
AC Current (ACA) - Flexible Clamp*	0 ~ 3000A (with optional probe)	0 ~ 3000A (with optional probe)	Both support the same optional high-current accessory.
DC Current (DCA)	0.1A ~ 1000A	0.1A ~ 1000A	Identical DC current measurement capability.
AC/DC Voltage	0.1V ~ 1000V	0.1V ~ 1000V	Identical.
Resistance	0.1Ω ~ 60MΩ	0.1Ω ~ 60MΩ	Identical.
Capacitance	0.01nF ~ 100mF	0.01nF ~ 100mF	Identical.
Frequency	0.01Hz ~ 10kHz	0.01Hz ~ 10kHz	Identical.
Temperature (via probe)	-40°C to 1000°C	-40°C to 1000°C	Identical.
Advanced Features
Trend Capture & Graph	Yes	Yes	Both can plot measurement trends in real-time on the color display.
Data Review (100 Graphs)	Yes	Yes	Both can store and review the last 100 trend graphs.
Inrush Current	Yes	Yes	Identical.
Low Impedance (LoZ) Mode	Yes	Yes	Identical.
Low Pass Filter (LPF)	Yes	Yes	Identical.
Non-Contact Voltage (NCV)	Yes	Yes	Identical.
Data & Utility Functions
Data Hold / Peak Hold	Yes	Yes	Identical.
Max/Min/Avg Hold	Yes	Yes	Identical.
Relative (Zero) Function	Yes	Yes	Identical.
Flashlight	Yes	Yes	Identical.
Auto Power Off	Yes	Yes	Identical.
Physical & Accessories
Jaw Opening	35mm (1.4 inches)	35mm (1.4 inches)	Identical.
Standard Accessories	Test Leads, Temp. Probe, Batteries, Case, Software	Test Leads, Temp. Probe, Batteries, Case	DT-9382 includes PC software. The flexible 3000A clamp is an optional accessory for both models.
Typical Use Case	Advanced diagnostics requiring remote monitoring, long-term data logging, or report generation. Ideal for energy audits, preventive maintenance programs, and engineers.	Advanced diagnostics where on-screen trend graphing is sufficient, and wireless data transfer is not required. Offers premium features at a potentially lower cost.
